- Model: DYDL-S185
- Main power: 170(KW)
- Weight: 1520(kg)
- Standby power: 185(KW)
- Size: 2515¡ Á980¡ Á1500(m
- Apparent power: 212.5(kva)
- +86 17652316769
- support@daiyuan-group.com
- 0755-23763425
- Model: 212.5(kva)
- Manufacturer: SDEC
- Bore: 114(mm)
- Main power: 185(KW)
- Stroke: 135(mm)
- Standby power: 204(KW)
- Speed: 1500(R/MIN)
- Rated fuel consumption: 220(g/KW.h)
- Displacement: 8.27(L)
- Power factor: 0.8 cos∮
- Model: DY-A-185
- Manufacturer: DAIYUAN
- Excitation mode: brushless self-excitation
- Main power: 170(KW)
- Connection method: flexible disc link
- Standby power: 185(KW)
- Bearing: 0.1mm high precision fully sealed maintenance-free bearing
- Rated voltage: 400/230(v)
- Stator and rotor material: Baosteel silicon steel sheet copper insulated wire winding
- Insulation/Protection class: H/IP23
- Model: HGM6110
- Manufacturer: Zhongzhi
- Display mode: LCD display
- Place of Origin: Zhengzhou
- Generator monitoring items: phase voltage 380V, line voltage 220V, frequency, current, power, reactive power, power factor, apparent reactive power
- Diesel engine monitoring items: speed, water temperature, oil pressure, charger voltage
- Automatic function: automatic detection of mains, automatic start, automatic stop
- Language type: support 16 national languages
- Diesel engine cooling water tank material: DAIYUAN special water tank
- Diesel engine cooling water tank cooling fin spacing: 0.80CM
- Fuel tank material: 2MM high-quality cold-rolled steel plate
- Muffler box: honeycomb double-layer industrial muffler
- Shock absorbing pad: bowl or square rubber shock-absorbing pad
- Battery: Camel brand maintenance-free battery
Every Reed Smith diesel generator set goes through several tests before leaving the factory:
1. Controller filling system
2. Connect the starter battery
3. Connect the fuel tank: oil inlet, oil return
4. Add antifreeze to the water tank
5. Connect the test load
6. Controller startup test
7. Load formal test: where No-load, 25%, 50%, 75%, 100%, 110% power sections need to be tested for 5 minutes respectively, After passing the quality inspection, the certificate will be stamped with a qualified seal, and the tester will sign it before loading the logistics and delivering it to the freight station.
DAIYUAN Promise
DAIYUAN solemnly promises you: Guarantee the new original model according to the contract requirements, genuine guarantee, fake one penalty ten, and resolutely do not use low power to pretend to be high power. The above commitments are all written into the contract, and we guarantee that the customer’s prosecution against us has no time limit and will never expire.
DAIYUAN promises to assist customers in need to identify the authenticity and real power of diesel generator sets at the request of customers. The identification results of the local after-sales service station of the diesel engine brand shall prevail. The customer shall contact the identification matters, and the cost shall be borne by DAIYUAN.
DAIYUAN promises the same configuration, lower price; same price, higher configuration. If it is a diesel generator set with the same configuration, as long as you find that the price of your peers is lower than ours within one month, DAIYUAN will refund the difference.
DAIYUAN solemnly promises you: 7 days no reason to return or exchange, 24 hours online after-sale, and lifetime tracking service for all units.
